Abbott FreeStyle Libre - Reader Symbols

Reader
Sensor
FreeStyle Libre Sensor
Placed in a clear display case.
USB Port
Used to charge the Reader
and connect it to a computer.
Test Strip Port
Non-functional test strip port
for demonstrations only.
Touchscreen
Home Button
Turns the Reader on/o
and returns to the Home
screen from any
other screen.
3
