3-14 Chapter 3
# HyperTransport Config:
Click <Enter> key to enter its submenu:
Phoenix – Award WorkstationBIOS CMOS Setup Utility
HyperTransport Config
Hammer to M1689 Freq. 800Mhz Item Help
Hammer to M1689 Width 16bits/8 bits
M1689 HTT Tristate Disabled
↑↓:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Hammer to M1689 Freq.:
This item selects the LDT Bus Frequency.
Hammer to M1689 Width:
This item selects the LDT Bus Width.
M1689 HTT Tristate:
This item enables or disables the M1689 HTT Tristate.
# Back to Advanced Chipset Features Setup Menu:
Init Display First:
This item selects to initialize AGP or PCI Slot first when the system boots.
[PCI Slot]: When the system boots, it will first initialize PCI.
[AGP]: When the system boots, it will first initialize AGP.
UL8
