Abit UL8 - PC Health Status Monitoring

BIOS Setup 3-23
3-8. PC Health Status
You can set the warning temperature for your computer system, and you can check the fan speeds and
power supply voltages of your computer system. The features are useful for monitoring all the important
parameters within your computer system. We call it the PC Health Status.
Phoenix – AwardBIOS CMOS Setup Utility
PC Health Status
Shutdown Temperature 95
O
C/203
O
F Item Help
CPU Warning Temperature 80 C/176 F
O O
FAN Fail Alarm Selectable Disabled
CPU FANEQ Control Enabled
- FanEQ Target Temperature 55 C/131 F
O O
- FanEQ Temp. Tolerance 5
O
C/41
O
F
- FanEQ Start Control 70%
- FanEQ Stop Control 30%
CPU Temperature 42 C/107 F
O O
System Temperature 30 C/100 F
O O
PWM Temperature 42
O
C/107 F
O
SYS FAN Speed 0 RPM
CPU FAN Speed 2000 RPM
AUX FAN Speed O RPM
CPU Core Voltage 1.42 V
DDR Voltage 2.68 V
DDR VTT Voltage 1.33 V
AGP VDDQ Voltage 1.52 V
ATX +12V 11.96 V
ATX +5V 4.62 V
ATX +3.3V 3.85 V
↑↓:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Shutdown Temperature:
You can set the processor shutdown temperature here. If the processor temperature exceeds the settings
value, system will force to shutdown to protect the processor not overheat.
CPU Warning Temperature:
This item lets you select the temperature at which you want the system to send out a warning message to
the PC speakers of when the temperature goes beyond either limit. You can select the temperatures you
want.
FAN Fail Alarm Selectable:
This item selects the fan that will be monitored for malfunction.
CPU FANEQ Control:
This item allows you to control the CPU fan speed. When set to [enabled], the following items become
selectable.
! FanEQ Target Temperature:
This item allows you to set a wanted temperature for the CPU.
