3-24 Chapter 3
! FanEQ Temp. Tolerance:
This item sets the high/low limits of the target temperature.
! FanEQ Start Control:
This item sets a specific speed for the fan when it is turned on. The fan will be turned on once the CPU
temperature exceeds the high limit temperature set by the above 2 items.
! FanEQ Stop Control:
This item sets a minimum speed for the fan. The fan will be running at this speed when the CPU
temperature is below the low limit temperature.
All Voltages, Fans Speed and Thermal Monitoring:
These unchangeable items list the current status of the CPU and environment temperatures, fan speeds,
and system power voltage.
NOTE: The hardware monitoring features for temperatures, fans and voltages will occupy the I/O
address from 294H to 297H. If you have a network adapter, sound card or other add-on cards that might
use those I/O addresses, please adjust your add-on card I/O address to avoid using these addresses.
