BIOS Setup 3-17
! USB Mouse Support Via:
This item allows you to select [BIOS] for using USB mouse in DOS environment, or [OS] in OS
environment.
OnChip Audio Controller:
This option enables or disables the audio controller.
# Super IO Device:
Click <Enter> key to enter its submenu:
Phoenix – AwardBIOS CMOS Setup Utility
SuperIO Device
Onboard FDC Controller Enabled Item Help
Onboard Serial Port 1 3F8/IRQ4
Onboard Parallel Port 378/IRQ7
Parallel Port Mode SPP
X - EPP Mode Select EPP1.7
X - ECP Mode Use DMA 3
↑↓:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Onboard FDC Controller:
Two options are available: Enabled and Disabled. The default setting is Enabled. You can enable or
disable the onboard FDC controller.
Onboard Serial Port 1:
This is used to specify the I/O address and IRQ of Serial Port 1. Six options are available: Disabled $
3F8/IRQ4 $ 2F8/IRQ3 $ 3E8/IRQ4 $ 2E8/IRQ3 $ AUTO. The default setting is 3F8/IRQ4.
Onboard Parallel Port:
Sets the I/O address and IRQ of the onboard parallel port. Four options are available: Disabled $
378/IRQ7 $ 278/IRQ5 $ 3BC/IRQ7. Default setting is 378/IRQ7.
Parallel Port Mode:
Four options are available: SPP $ EPP $ ECP $ ECP+EPP. The default setting is SPP mode.
! EPP Mode Select:
Two options are available: EPP1.7 $ EPP1.9. The default setting is EPP 1.7 When the mode selected for
the parallel port mode is EPP, the two EPP version options are available.
User’s Manual
