3-18 Chapter 3
! ECP Mode Use DMA:
Two options are available: 1 $ 3. The default setting is 3. When the mode selected for the parallel port
mode is ECP, the DMA channel selected can be Channel 1 or Channel 3.
# Onboard PCI Device:
Click <Enter> key to enter its submenu:
Phoenix – AwardBIOS CMOS Setup Utility
Onboard PCI Device
Onboard LAN Controller Enabled Item Help
- LAN Boot ROM Disabled
↑↓:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Onboard LAN Controller:
This option enables or disables the LAN controller.
! LAN Boot ROM:
This item allows you to use the boot ROM (instead of a disk drive) to boot-up the system and access the
local area network directly.
UL8
