2.4 Power Cables Connections
 Power Cable Sizing
The drawing below shows the positions of power terminals.
Mains(X
10)/ Bypass(X40) Output
Battery
10kVA Power Terminal Positions
Mains(X10)/ Bypass(X40) Output Battery
20kVA Power Terminal Positions
