Ablerex TAURUS 40 kVA - Page 8

 10-20kVA Internal View
10
12
14
15
13
16
17
11
1
2
3
4
5
6
7
8
9
A
○
1E
Parallel Communication Ports
A
○
2E
HMICommunicationPort
A
○
3E
Communication Selector for
Service only
A
○
4E
USB Port for Service Only
A
○
5E
Terminal Resistor Setting Switch
for Parallel Communication
A
○
6E
Status LED Indictors
A
○
7E
EPO
A
○
8E
Backfeed Protection
A
○
9E
MBP Detector
A
○
10E Communication Card Slot1
A
○
11E
Communication Card Slot2
Please find the detail descriptions of
above items on section 2-5.
A
○
12E
Mains Input Switch
A
○
15E
Output Switch
A
○
13E
Bypass Input Switch
A
○
16E
Fuse for Control Power
A
○
14E
Manual Bypass Switch
A
○
17E
Battery Tray (Option)
6
192321262008007
