122
Click on the checkbox to enable or disable the WDR function.
Set the Wide Dynamic Level higher to enhance the WDR function.
HLC
(High Light Compensation) Overexposure at the edge of bright light sources is reduced (e.g. car headlights).
A higher threshold means high reduction. Function only with deactivated WDR.
White balance
Here you select the lighting conditions in which the camera is installed.
You can choose from the following options: “Manual”, “AWB1”, “WB Locked”, “Fluorescent Lamp”,
“Incandescent Lamp”, “Warm Light”, “Natural Light”.
Manual
You can adjust the white balance with the following values manually.
Locked WB
The white balance is performed once and saved.
Other
Use additional white balance options to adjust the function to the light levels.
Fluorescent Lamp
Adjusts the white balance to fluorescent lamp lighting conditions.
Image enhancement
Digital Noise Reduction
You can enable (Normal Mode) or disable the noise reduction.
Noise Reduction Level / 2D/3D DNR
Set the level for noise reduction here.
Grey Scale
This function limits the range of the grey scale representation. This can be beneficial in the case of very light
image content.
Video Settings
Mirroring
Three different options for image mirroring are possible (horizontal, vertical, hor. + vert.)
Rotate (Vertical display)
This setting rotates the image to increase the vertical angle of view. It is necessary to rotate the camera
module by 90° when doing this.
Video Standard
Select the video standard corresponding to the available power frequency.
