Abus PPIC32020 User Manual

10
English
3.3. White light LED
PPIC35520
LED
Status
Description
White light LED
ring
On
Connection to intercom established / call
accepted
Flashing
Call button has been pressed, call waiting
Off
No active connection
3.4. Call button (PPIC35520 only)
Pressing the call button triggers the following response from the intercom system:
 Call triggered
 Relay for external doorbell (C2/C1) is triggered
 The white LED ring begins to flash
3.5. RFID Reader (PPIC35520 only)
You can program and use the ABUS AZ5502 proximity chips in the intercom with the help of the built-
in RFID reader. The RFID reader is located behind the loudspeaker, just above the call button.
To do this, enable programming in the intercom’s advanced settings and hold the chip in front of the
intercom until you hear a beeping sound and the app displays the next step.
You can perform different actions by using the chip in different ways.
Response
Use
Response
Action
Hold the chip just in front
of the RFID reader for
one second
Beeps 1x
Relay (B2/B1) triggered
Beeps 3x
Chip could not be read
Chip not recognised
Hold the chip in front of
the RFID reader until
there is a response.
Beeps 2x
-
Beeps 3x
Chip could not be read
Chip not recognised
