4.4.4. Adjustable lens
The door station’s lens can be adjusted on the back by up to 7.5 % vertically and 2.5 % horizontally.
To adjust the lens, loosen the screw using the triangle screwdriver provided. We recommend you first
connect your intercom to the App2Cam Plus on your network before final installation in order to ensure
it is perfectly positioned. Fix the position of the lens by tightening the screw on the rear of the bracket
using the triangle screwdriver.
4.4.5. Final installation
To complete installation, unscrew the aerial from the door station and mount the door station on the
mounting plate using the triangle screwdriver and the four triangular screws provided. Screw the aerial
back on to the door station and affix the cover to the door station. Finally, replace the call button
pressure plate and the doorbell cover.
