AC Infinity CONTROLLER 69 User Manual

15
UIS COMPATIBILITY
EXTENSION CABLE
Use male-to-male UIS extension cords to connect devices with female UIS ports at an extended
range from your controller.
EXPANSION DONGLE
The expansion dongle will allow you to connect 2 or 4 devices with a single port and can support
additional dongles to create more expansion ports (up to 64 units supported with the use of 20
dongles*). Intended for exclusive use with AC Infinity controllers built with UIS ports.
UIS M - M
4 PORT DONGLE
UIS M - M
2 PORT DONGLE
MOLEX ADAPTER
Use the included Molex adapter to plug inline fans with 4-pin Molex connectors into this controller.
Plug your fan's Molex connector into the adapter. Then plug the adapter into the controller.
UIS M - 4PIN F
ADAPTER
UIS M - M
CORD
UIS M - M
CLIP FAN CORD
*UIS extension cord and dongle sold separately

AC Infinity CONTROLLER 69 Specifications

General

Model Number	CONTROLLER 69
Outlets	4
Display	LCD
Power Input	100-240V AC
App Compatibility	AC Infinity App (iOS and Android)
Sensors	Temperature, Humidity
Mounting	Wall Mountable
Wireless Connectivity	Wi-Fi
Control Modes	Schedule
