104 CHAPTER 16
The Parameters
OFF Now,the CUTOFF and CUTOFF 2
knobs are no longer linked and CUTOFF
2 operates absolutely in a control range
of 0 to 127. In this case the CUTOFF and
CUTOFF 2 knobs are two independent
control features that determine the
respective cutoff frequencies for Filter-1
and 2.
CUTOFF LINK pertains exclusively to the
CUTOFF 2 knob and the corresponding
parameter. CUTOFF 2 has no influence
on the other parameters of the second
filter.
01111111111111111112
1 FILTER2
CutoffLink On≤
61111111111111111154
Filters
[XP] BALANCE Has different functions
depending on the FILTER ROUTING set-
ting (see appropriate section as well): In
the parallel FILTER ROUTING operating
modes PAR 4 and SPLIT, it controls the
balance of volume levels between the
two filters - or in actuality SATURATION
and Filter-2.
Technically, in the serial FILTER ROUTING
operating modes SER 4 and SER 6, the
left half and the right half of the control
range address different parameters:
When the knob is set to the far left posi-
tion, you will hear Filter-1/Saturation
exclusively, whereas Filter-2 is blended
into the mix as you rotate the knob
towards the center position. When the
knob is set to the far right position, you
will hear Filter-2 exclusively, whereas Fil-
ter-1/Saturation is blended into the mix
as you rotate the knob towards the cen-
ter position.
Consequently, you must set FILTER BAL-
ANCE to the center position if you want
both filters in series (in equal amounts)
in the signal path.
01111111111111111112
1 FILTERS
Balance +10≤
61111111111111111154
