110 CHAPTER 16
The Parameters
SINE Contour morphs from sine to a tri-
angle wave (Contour to the left) or to a
square wave (Contour to the right).
TRIANGLE Contour morphs from a tri-
angle to a declining (Contour to the left)
or ascending sawtooth (Contour to the
right).
SAWTOOTH Contour morphs from a
linear declining sawtooth or decay to
any exponentially declining decay(Con-
tour to the left) or to a square (Contour
to the right).
SQUARE Contour modulates the pulse
width of the square wave.
KEY FOLLOW Controls the intensity of
the KEY FOLLOW function - i.e. the rate
at which the LFO follows the pitch of a
played note. At a value of 0, KEY FOL-
LOW is deactivated. At a value of 127,
the rate doubles with each octave.
01111111111111111112
1 LFO1
Keyfollow Off≤
61111111111111111154
LFO 2
RATE Same as LFO 1
SHAPE Same as LFO 1
CONTOUR Same as LFO 1
KEYFOLLOW Same as LFO 1
LFO 3
RATE Same as LFO 1
SHAPE Same as LFO 1
KEYFOLLOW Same as LFO 1
