Accu-Chek Aviva Plus User Manual

9
Your New System
1
1. Cap with Comfort Dial Depth
Selection
For fingertip testing.
2. Ejector
Slide to release lancet.
3. Release Button
Press to prick.
4. Priming Button
Press to prime.
5. Lancet
6. AST Cap
For Alternate Site Testing (available
upon request from the ACCU-CHEK
Customer Care Service Center at
1-800-858-8072).
The ACCU-CHEK Softclix Lancing Device
NOTE
Some items may be sold separately.
51801_07021933001.indb 9 5/7/14 8:52 AM

Accu-Chek Aviva Plus Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Coding	No coding required
Dimensions	94 x 52 x 21 mm
Measuring Range	10-600 mg/dL
Display	LCD
Memory	500 results
Battery Type	CR2032
Battery Life	Approximately 1000 tests
Automatic Power Off	90 seconds after use
Weight	59 g with battery
