Accu-Chek Aviva User Manual

Chapter 1: Understanding Your New System
The Accu-Chek Aviva Meter
Infrared (IR) Window –
Transfers data from the
meter to a computer or
PDA.
Display –
Shows results,
messages, and results
stored in memory.
Right and Left
Arrow Buttons –
Press to enter
memory, adjust settings,
and scroll through results.
Test Strip Slot –
Insert test strip here.
On/Off/Set Button –
Turns the meter on or
off and sets options.
Code Chip Slot –
Insert code chip into
this opening.
Battery Door –
Flip open the battery
door by pushing the
tab in the direction of
the arrow.
6

Accu-Chek Aviva Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Coding	No coding required
Battery Life	Approximately 1000 tests
Memory	500 test results
Battery Type	1 x 3V lithium (CR2032)
Operating Humidity	10% to 90% RH
Meter Weight	59 g
Measuring Range	10 mg/dL to 600 mg/dL
Automatic Shut Off	After 90 seconds of inactivity
