Acculab ECL6 - Specifications; General Specifications; Specifications of Individual Models

30
No of keys 6
Display LCD, 6 digits, character height: 25 mm, 7 segment with backlight (amber)
Functions 1. Zero, 2. Tare, 3. Counting, 4. Checkweighing, 5. Net/gross weight, 6. Toggle between weight
units, 7. Auto power off (optional battery mode)
Maximum readability 15000d
Temperature range –10 to +40°C RH85% no condensation
Line power supply Built-in 100-240V AC (+/- 10%), 50Hz, 15.5 VA (with battery charger circuit)
4 VA (without battery charger circuit)
DC power operation Optional using 6 “D” size 1.5V dry battery
Load plate Platform code: DC, ED, FE, GF, GG, IG stainless steel; LL, NL, NN, RN, RR, WR painted steel
Housing material ABS
Column Length 350 mm, 500 mm & 750 mm
Measurement category Category 1, maximum 8.5V
Pollution degree Degree 2
Compliance CE
Specifications of the Individual Models:
Model ECL6EDP FCC15EDP ECL30EDP ECL60EDP ECL150EDP ECL150EDP
Weighing capacity (kg) 6 15 30 60 150 300
Verification (g) 0.5 12510100
Readability (+±g)1241020100
Linearity (+±g)1241020100
Operating temperature –10…+40°C
Accessories (Options)
– RS-232 interface (cable 2 m with DB9 pins for PC connection)
– RS-232 interface (cable 2 m with DB25 pins for YDP03 printer)
– Printer YDP03-0CE
