Acculab ECL6 - SBI Interface Protocol Description

21
Output Format with 22 Characters
The following data block format is output:
I IIIIIVWWWWWWWWW UUUCRLF
I : ID W : Weight value
V : +/- sign U : Unit
ID Codes
S t a t Indicates a special weighing platform status, e.g., initialization, self-test, adjustment/calibration
N Indicates net or gross value
N 1 Indicates net value with 1
st
tare memory assigned (not main tare)
N 2 Indicates net value with 2
nd
tare memory assigned (not main tare)
S / N Indicates equipment serial number
M o d e l Indicates equipment Model
Plus/Minus Sign
+ Plus sign
– Minus sign
Space (i.e., no plus or minus sign; if weight value is 0 or if output does not include a weighed value)
Unit
No stable parameter.; no weighed value
g Grams
k g Kilograms
l b Pounds
o z Ounces
t Tons
Special Codes
The data block may contain special information.
Special status-dependent codes:
1 2345678910111213141516171819202122
S1 S2 CR LF
The following status codes are output for “S1” and “S2”:
: Taring
C : Internal calibration
- - : All numerals shown in stable readout
H : Overload
L : Underload
SBI Interface Protocol Description
