⑦ Lift up the fixing lever to the arrow direction as shown in the picture.
⑧ Slightly press the rubber pad located at the inner body cover to make the height meter body put
into easily.
Put the height meter body in the body cover. (*Note: RS-232C connector at the bottom of the
height meter body should be placed at the connector socket.)
⑨ Pull the fixing lever down and fix it as shown in the picture.
Body
Body cover
RS
-
232C
connector
Connector
socket
Rubber pad
Rubber pad
