Accurex XRRS Series User Manual

Fire Ready Hood14
3. Plug gas shut off assembly box (5 ft. power cord) into
115VAC 5-15 receptacle near the range.
4. There will be two (2) 10 ft. plug and play cables
coiled up in the hood. Run these through a two inch
knockout in the control j-box down to the gas shut off
assembly, connecting them per the diagram shown:
RANGE (BY OTHERS)
115VAC 15A
POWERED
RECEPTACLE
(BY OTHERS)
GAS SHUT OFF
ASSEMBLY BOX
11
GAS LINE
PIPE GAS LINE INTO GAS VALVE INLET, THEN
OUT OF GAS VALVE OUTLET TO RANGE.
FAN DETAIL - ECM INTERNAL (FRONT RECIRCULATION)
VOLT
115 60 1
FREQ PHASE INPUT POWER WEIGHT DUCT CONN
120 WATTS 4 LBS NONE
NOTES:
1) FAN MOUNTED AND
WIRED INSIDE HOOD BY
FACTORY
2) DISCHARGES THROUGH
CHARCOAL FILTER ON
FACE OF HOOD BACK
INTO SPACE
DRAWING NOT TO SCALE
FRONT RECIRCULATING
INTERNAL FAN
1.70
10.00
3.90
5.02
FAN DETAIL - FAN BY OTHERS
NOTES:
1) FAN PROVIDED BY
OTHERS
2) 0-10VDC SPEED
REFERENCE AND
115VAC RUN ENABLE
SIGNAL PROVIDED IN
QC2 QUICK CONNECTOR
AT HOOD
3) 115VAC SIGNAL CAN
POWER MAX 1/4HP
115VAC MOTOR. FOR
DRIVING MOTORS
LARGER THAN 1/4HP,
UTILIZE MOTOR
STARTER (STARTER
PROVIDED BY OTHERS)
DRAWING NOT TO SCALE
3
4
QC2
1
2
3
4
2
1
0-10VDC + SIGNAL
115VAC L (5A RES. MAX)
0-10VDC - SIGNAL (GND)
115VAC N (5A RES. MAX)
IN HOOD
JUNCTION BOX
FAN BY OTHERS
FAN DETAIL - ECM INTERNAL (REAR DISCHARGE)
VOLT
115 60 1
FREQ PHASE INPUT POWER WEIGHT DUCT CONN
120 WATTS 4 LBS 5" x 12"
NOTES:
1) FAN MOUNTED AND
WIRED INSIDE HOOD BY
FACTORY
2) FIELD TO ALIGN WITH 5"
x 12" MINIMUM DUCT
OUT OF THE BACK OF
THE HOOD (PROVIDED
BY OTHERS).
DRAWING NOT TO SCALE
REAR DISCHARGE
INTERNAL FAN
1.70
10.00
3.90
5.02
FAN DETAIL - ECM EXTERNAL INLINE
1.50
6.69
1.00
12.00
16.00
VOLT
115 60 1
FREQ PHASE INPUT POWER WEIGHT DUCT CONN
166 WATTS 16 LBS 12" ROUND
NOTES:
1) INSTALL FAN
VERTICALLY INLINE IN
DUCT BETWEEN HOOD
AND ROOF CAP
2) HOOD SHOULD BE
ADAPTED FROM 8"
COLLAR TO MINIMUM 12"
DIA. RIGID METALLIC
DUCT
3) PROVIDED WITH 50FT
PLUG AND PLAY CABLE
COILED UP IN HOOD
LABELED "FAN"
4) 35FT MAX DUCT LENGTH
DRAWING NOT TO SCALE
INLINE FAN WITH
NFPA 101 (500 CFM)
FAN DETAIL - FAN BY OTHERS
NOTES:
1) FAN PROVIDED BY
OTHERS
2) 0-10VDC SPEED
REFERENCE AND
115VAC RUN ENABLE
SIGNAL PROVIDED IN
QC2 QUICK CONNECTOR
AT HOOD
3) 115VAC SIGNAL CAN
POWER MAX 1/4HP
115VAC MOTOR. FOR
DRIVING MOTORS
LARGER THAN 1/4HP,
UTILIZE MOTOR
STARTER (STARTER
PROVIDED BY OTHERS)
DRAWING NOT TO SCALE
3
4
QC2
1
2
3
4
2
1
0-10VDC + SIGNAL
115VAC L (5A RES. MAX)
0-10VDC - SIGNAL (GND)
115VAC N (5A RES. MAX)
IN HOOD
JUNCTION BOX
5 FT. CORD
GAS FLOW
VALVE RESET
POWER RESET
FUEL ACTIVATION
CONTACT RATING
12 VAC - 5 AMP
AUXILIARY INTERFACE
CONTACT RATING
115 VAC - 5 AMP
RIGHT SIDE
VIEW
TOP VIEW
GAS SHUT OFF ASSEMBLY BOX
MOUNTED BEHIND RANGE
(FRONT VIEW)
GAS /ELEC DISC
CABLE
6 FT. CABLES FROM HOOD
(ATTACHED TO HOOD)
9 PIN
PLUG AND PLAY
CABLE
4 PIN
PLUG AND PLAY
CABLE
GAS FLOW
VALVE RESET
POWER RESET
FUEL ACTIVATION
CONTACT RATING
12 VAC - 5 AMP
AUXILIARY INTERFACE
CONTACT RATING
115 VAC - 5 AMP
RIGHT SIDE
VIEW
TOP VIEW
GAS SHUT OFF ASSEMBLY BOX
MOUNTED BEHIND RANGE
(FRONT VIEW)
GAS /ELEC DISC
CABLE
6 FT. CABLES FROM HOOD
(ATTACHED TO HOOD)
9 PIN
PLUG AND PLAY
CABLE
4 PIN
PLUG AND PLAY
CABLE
GAS FLOW
VALVE RESET
POWER RESET
FUEL ACTIVATION
CONTACT RATING
12 VAC - 5 AMP
AUXILIARY INTERFACE
CONTACT RATING
115 VAC - 5 AMP
RIGHT SIDE
VIEW
TOP VIEW
GAS SHUT OFF ASSEMBLY BOX
MOUNTED BEHIND RANGE
(FRONT VIEW)
TOP VIEW
RIGHT SIDE
VIEW
GAS /ELEC DISC
CABLE
10 FT. CABLES FROM HOOD
(ATTACHED TO HOOD)
9 PIN
PLUG AND PLAY
CABLE
4 PIN
PLUG AND PLAY
CABLE
Electric (if applicable)
1. Plug range power cord into 250VAC receptacle on
electric shut off assembly box.
2. Plug gas shut off assembly box (2½ ft. 4-prong power
cord) into 250VAC 14-50 receptacle near the range.
3. There will be two (2) 10 ft. plug and play cables
coiled up in the hood. Run these through a two inch
knockout in the control j-box down to the electric
shut off assembly, connecting them per the diagram
shown.
RANGE (BY OTHERS)
RIGHT SIDE
VIEW
RANGE 250VAC
POWER CORD
ELECTRIC SHUT OFF
ASSEMBLY BOX
RANGE (BY OTHERS)
ELECTRIC SHUT OFF
ASSEMBLY BOX
MAX 250VAC
MAX 50A 4-PRONG
POWERED
RECEPTACLE
(BY OTHERS)
2½ FT. CORD
ELECTRIC SHUT OFF ASSEMBLY BOX
MOUNTED BEHIND RANGE
(TOP VIEW)
BACK VIEW
LEFT SIDE
VIEW
10 FT. CABLES FROM HOOD
(ATTACHED TO HOOD)
4 PIN
PLUG AND PLAY
CABLE
9 PIN
PLUG AND PLAY
CABLE
