Accurex XRRS User Manual

13
Fire Ready Hood
Electric Disconnect Box (if applicable)
Gas Disconnect Valve (if applicable)
50AMP 250V
NEMA 14-50
L1 208-220 VAC Black Hot
L3 208-220 VAC Red Hot
T1 208-220 VAC Black Hot
T3 208-220 VAC Red Hot
By others
Provided by Accurex
Provided by others
By Accurex
T1
L1
T3
L3
50 AMP 208-240 VAC Single Phase
Supply Line (by others)
110 VAC Coil
Wire Nut
Neutral
GND
6 Position
Orange
Connector
6 Position
Grey
Connector
15 AMP 110-120 VAC
Supply Line (by others)
Metal Clad to 110-120 VAC
Power Disconnect
(Black Tape) - 14/2
Metal Clad Wire from 110-120 VAC
Supply Line (Red Tape)
Green Ground
Wire nut inside power
disconnect box
Green Ground
Black Hot
110-120 VAC 14/2
Hood
White Neutral
Black Hot 110-120 VAC
Junction
Box
White Neutral
Contactor 50A
Supplied
Power Disconnect Box
8” x 6” x 4”
Back Support
Mounting Bracket
GND
NEUT
HOT
GND
NEUT
HOT
H
N
H
HH
}
}
}
Metal Clad Wire from 110-120 VAC
Supply Line (Red Tape)
6 Position
Orange
Connector
6 Position
Grey
Connector
15 AMP 110-120 VAC
Supply Line (by others)
Multiconductor
(4 Conductor)
110-120 VAC Gas Solenoid
Green
Green Ground
Green Ground
Black
Hood
White Neutral
White Neutral
Black Hot 110-120 VAC
Black Hot 110-120 VAC
Junction
Box
Junction Box
Wire Nut
White
Back Plate
GND
NEUT
HOT
GND
NEUT
HOT
Metal Clad to 110-120 VAC
Power Disconnect
(Black Tape)
