Accurex XXDW User Manual

39
ACCUREX
PART NUMBER
REGISTERS
452700 24 x 8 Aluminum Single Deflection H-OB
452701
36 x 8 Aluminum Single Deflection H-OB
452702
36 x 8 Aluminum Single Deflection H-OB
452703
44 x 8 Aluminum Single Deflection H-OB
453796 24 x 12 Aluminum Single Deflection H-OB
453797 36 x 12 Aluminum Single Deflection H-OB
453798 38 x 12 Aluminum Single Deflection H-OB
453799 44 x 12 Aluminum Single Deflection H-OB
452729
24 x 8 Aluminum 38
° Fixed Blade RA-OB
452730
30 x 8 Aluminum 38° Fixed Blade RA-OB
452731
36 x 8 Aluminum 38° Fixed Blade RA-OB
452732
38 x 8 Aluminum 38° Fixed Blade RA-OB
452733
44 x 8 Aluminum 38° Fixed Blade RA-OB
ACCUREX
PART NUMBER
SWITCHES
850551 Light Switch Only
851776 Fan Switch Only
851777 Light Switch & Fan Switch ( 2 switches)
851778 Fan Switch & Heat Switch (2 switches)
851779 Exhaust, Fan & Supply Switch (2 switches)
851780 Light, Fan & Heat Switch (3 switches)
851781 Light, Exhaust, Supply Separate Switch (3 switches)
851782
Exhaust, Supply, Heat Separate Switch (3 switches)
851783 Light, Exhaust, Supply, Heat Separate Switch (4 switches)
851784 Fan Switch & Temper (3 position) (2 switches)
851510 Light, Fans, & Temper (3 position) (3 switches)
851511 Exhaust, Supply, & Temper (3 position) (3 switches)
851512
Light, Exhaust, Supply, & Temper (3 position) (4 switches)
851618 Automatic Fire Damper Test Switch
ACCUREX
PART NUMBER
MISCELLANEOUS
451131 Grease Cup
453498 Glass Globes for hood lights (clear)
851744 Grease Extractor Filter Removal Tool
851834 Baffle Filter Removal Tool
851747 High Velocity Cartridge Filter Removal Tool
Replacement Parts
