Upon receiving the equipment, check for both obvious and hidden damage. If damage is found, record all
necessary information on the bill of lading and file a claim with the final carrier. Check to be sure that all parts of
the shipment, including accessories, are accounted for.
STORAGE: If a kitchen hood must be stored prior to installation it must be protected from dirt and moisture.
Indoor storage is recommended. For outdoor storage, cover the hood with a tarp to keep it clean, dry, and
protected from UV (Ultra Violet) Radiation damage.
Improper storage which results in damage to the unit will void the warranty.
HOOD
MODEL
HOOD DEPTH (MULTIPLY BY LENGTH) FOR HOOD WEIGHT
3 ft.
.914 m
3.5 ft
1.067 m
4 ft
1.2192 m
4.5 ft
1.3716 m
5 ft
1.524 m
5.5 ft
1.6764 m
6 ft
1.8288 m
6.5 ft
1.9812 m
7 ft
2.1336 m
7.5 ft
2.286 m
XB, XK,
XXEW
30 lbs/ ft.
44.64
kg/m
32 lbs/ft
47.62
kg/m
35 lbs/ft
52.08
kg/m
38 lbs/ft
56.54
kg/m
40 lbs/ft
59.52
kg/m
XB, XX,
XXDW
36 lbs/ft
53.57
kg/m
38 lbs/ft
56.44
kg/m
41 lbs/ft
61.01
kg/m
44 lbs/ft
65.47
kg/m
46 lbs/ft
68.45
kg/m
XB, XK,
XXFW
40 lbs/ft
59.52
kg/m
44 lbs/ft
65.47
kg/m
48 lbs/ft
71.42
kg/m
52 lbs/ft
77.38
kg/m
XB, XK,
XXCW
48 lbs/ft
71.42
kg/m
51 lbs/ft
71.89
kg/m
54 lbs/ft
81.35
kg/m
57 lbs/ft
84.82
kg/m
XB, XK,
XXSW
44 lbs/ft
65.47
kg/m
48 lbs/ft
71.42
kg/m
52 lbs/ft
77.38
kg/m
56 lbs/ft
83.33
kg/m
XGEW
39 lbs/ft
58.03
kg/m
41 lbs/ft
61.01
kg/m
44 lbs/ft
65.47
kg/m
47 lbs/ft
69.94
kg/m
49 lbs/ft
72.91
kg/m
XGDW
45 lbs/ft
66.96
kg/m
47 lbs/ft
69.94
kg/m
50 lbs/ft
74.40
kg/m
53 lbs/ft
78.86
kg/m
55 lbs/ft
81.84
kg/m
XGFW
49 lbs/ft
72.91
kg/m
53 lbs/ft
78.86
kg/m
57 lbs/ft
84.82
kg/m
61 lbs/ft
90.77
kg/m
XGCW
57 lbs/ft
84.82
kg/m
60 lb/ft
89.28
kg/m
63 lbs/ft
93.74
kg/m
66 lbs/ft
98.21
kg/m
XGSW
53 lbs/ft
78.86
kg/m
57 lbs/ft
84.82
kg/m
61 lbs/ft
90.77
kg/m
65 lbs/ft
96.72
kg/m
XB, XK,
XXEV
52 lbs/ft
77.38
kg/m
54 lbs/ft
81.35
kg/m
56 lbs/ft
83.33
kg/m
58 lbs/ft
86.30
kg/m
61 lbs/ft
90.77
kg/m
63 lbs/ft
93.74
kg/m
XB, XK,
XXFV
61 lbs/ft
90.77
kg/m
66 lbs/ft
98.21
kg/m
68 lbs/ft
101.18
kg/m
72 lbs/ft
107.14
kg/m
75 lbs/ft
111.6
kg/m
79 lbs/ft
117.55
kg/m
XB, XK,
XXCV
81 lbs/ft
120.53
kg/m
84 lbs/ft
124.99
kg/m
87 lbs/ft
129.46
kg/m
90 lbs/ft
133.92
kg/m
XB, XK,
XXSV
66 lbs/ft
98.21
kg/m
69 lbs/ft
102.67
kg/m
72 lbs/ft
107.14
kg/m
76 lbs/ft
113.09
kg/m
79 lbs/ft
117.55
kg/m
Receiving and Handling
