Diagnostics Menu
[4A]Select diagnostic
output:
A – Envelope Detect
B – Filter
This option selects the diagnostic mode. In use, a
PC can be used to display the sonic-analog
signals showing quality, amplitude, and noise for
troubleshooting.
[4B] Test current output:
Enter a value between
4 and 20
Forces a known 4 – 20 mA output when a
value is entered and the center button is
pressed. Value resets to airflow output once
the menu is exited.
