ACE095 Page 13 of 17 Rev Date: 12.7.2021
7. Chassis Cover
Location: The chassis cover is located on the top and is held in place with two Phillips screws.
Type and number of fastenings: Two (2) screws.
Tools required: Phillips screwdriver.
Procedure: Remove two screws and gently pull the handle backwards.
Selective Treatment/Special Handling Per Annex VII, Directive 2012/19/EU: None
