ACE095 Page 9 of 17 Rev Date: 12.7.2021
3. Processor
Location: The processor is found on the motherboard of the desktop. As shown in the photo
below, the processor is located under the heat sink. There can only be one processor on the
motherboard for this model. The processor could consist of a push-pin based Intel heatsink.
Type and number of fastenings: Push-Pin
Tools required: NA
Procedure: Intel Processor: Remove the push-pin from the base of the heatsink and lift the
processor heatsink module off of the processor socket.
Selective Treatment/Special Handling Per Annex VII, Directive 2012/19/EU: Any printed circuit
boards within the processor must be removed separately from the processor and shall be
disposed or recovered in compliance with Directive 2008/98/EC.
