LCD Panel Installation 0
1. Put LCD panel on the LCD cover. Refer to Figure 3-36.
2. Put LVDS cable (C) in the cable guides. Refer to Figure 3-37.
3. Install and secure six (6) screws (A) to the LCD panel. Refer to Figure 3-36.
4. Install LCD bezel.
ID Size Quantity Screw Type
A M2.5*4.0 6
