Machine Maintenance 3-55
3. Connect the webcam cable to the webcam module (1).
Figure 3-80. Webcam & Microphone Cables
4. Connect the microphone cable (2).
5. Secure the LCD panel using four screws.
Figure 3-81. LCD Panel Screws
Table 3-81. Screws
Step Screw Quantity Screw Type
LCD Panel Reassembly M2.5 × L4 4
