Acer Aspire 4352 - External Module Disassembly Steps

3-8 Machine Maintenance
External Module Disassembly Process 0
External Modules Disassembly Flowchart 0
Figure 3-2. External Modules Disassembly Flowchart
Table 3-2. Screw List
Step Screw Quantity Acer Part Number
ODD Module Disassembly M2.5 x L6 1 86.00E12.536
Back Cover Disassembly M2.5 x L6 3 86.00E12.536
Keyboard Disassembly M2.5 x L6 2 86.00E12.536
REMOVE BATTERY
PACK
DIMM
MODULES
WLAN
BOARD
HDD
MODULE
ODD
MODULE
BACK
COVER
KEYBOARD
