6-6 FRU (Field Replaceable Unit) List
LCD Assembly 0
Figure 6-2. LCD Assembly Exploded Diagram
Table 6-2. LCD Assembly Exploded Diagram
No. Description Part Number
1 LCD screw covers –
2 LCD bezel 60.V4201.004
3 LCD left hinge bracket 34.4NR02.001
4 LCD right hinge bracket 34.4NR01.001
5 LCD panel LK.14008.004
6 Webcam board 57.V4201.001
7 LCD-webcam coaxial cable 50.4IQ01.031
8 LCD cover 60.V4201.005
