Acer Aspire 4743Z - Removing the RTC Battery

3-38 Machine Maintenance
Removing the RTC Battery 0
1. Refer to Removing the Palmrest Module/Upper Cover.
2. Insert a small flat-blade screwdriver between the battery and spring latch to dislodge the
battery, then remove the battery.
Figure 3-53. RTC Battery
NOTE:
NOTE:
The RTC battery has been highlighted with a yellow circle in Figure 3-47. Detach the
RTC battery and follow the local regulations for disposing it.
