Acer Aspire 4743Z - LCD Reassembly Process

3-58 Machine Maintenance
LCD Reassembly Process 0
Replacing the Antennas 0
1. Place the antenna cables on the LCD cover.
Figure 3-88. Antennas
2. Secure the cables with the tin foil tapes and route the antenna cables to the cable guides.
Figure 3-89. Antennas
