Acer Aspire 4743Z - Removing the Battery Pack

Machine Maintenance 3-9
Removing the Battery Pack 0
1. Turn base unit over.
2. Use a pen to slide the battery release latch to release the battery from the battery bay.
Figure 3-3. Battery Pack
3. Remove the battery from the battery bay.
Figure 3-4. Battery Pack
NOTE:
NOTE:
The battery has been highlighted with the yellow oval in Figure 3-4. Disconnect the
battery and follow local regulations for disposal.
