Acer n50 User Manual

Appendix A: Exchanging and updating data using Bluetooth® Utility
(optional)
Bluetooth® Settings
86
Apply Power To The Bluetooth® Hardware
The first screen Bluetooth Settings has ON/OFF buttons to apply/remove power to the
hardware.
Bluetooth
®
Settings
The Bluetooth Settings screen's tabs are :
•Gerneral
– User profile selection
– Bluetooth status (ON/OFF) indicator
– Hardware power control (ON/OFF)
– Shortcut to the Bluetooth Manager
• Accessibility
– Set the device name
– The handheld's Bluetooth Device Address (BDA)
– Determine which remote devices are allowed to connect
– Determine whether remote devices can "see" this handheld
• Service tabs-Bluetooth can provide four services. They are:
– File Transfer-set the highest-level directory on this handheld that remote
devices will be able to access.
– Information Exchange-Set the default business card (Pocket Outlook
contact entry)
– Serial Port-Bluetooth serial port information
– Dial-up Networking-configure the COM port, baud rate and flow control.
– Personal Network Server-configure the service availability
• About-there are no configurable options on this tab.
– Software version information
– Copyright information
– Website and Technical Support links.
Bluetooth® Manager
The Bluetooth Manager allows you to create, manage, and use Bluetooth connections
with remote devices.
To access Bluetooth Manager:
• From the Today screen, tap and then:
– tap > Programs > Bluetooth Manager.
or
• In the lower-right corner of the screen, tap the Bluetooth icon and then select
Bluetooth Manager.
Bluetooth Manager has :

Acer n50 Specifications

General

Internal memory	0.064 GB
Built-in processor	PXA272
Processor frequency	0.312 GHz
Display diagonal	3.5 \
Display resolution	240 x 320 pixels
Display number of colors	65536 colors
I/O ports	1 x USB 1 x serial
Headphone outputs	1
Bluetooth	Yes
Battery capacity	1060 mAh
Battery life (max)	8 h
GPS (satellite)	No
RFID reader	-

Weight and Dimensions

Depth	120 mm
Width	70 mm
Height	17.4 mm
Weight	150 g
