INTRODUCTION
Connections
7
621 3 4 5
8
10111213 16
9
1514
No. Item 14 IO 15 IO
1. HDMI 2 (v1.4) Connector √ √
2.
HDMI 1(v2.0)(4K) / MHL Connector
√ √
3. USB Power Out (5V 1.5A) Connector √ √
4. VGA In / VGA In 1 Connector √ √
5. Composite Connector √ √
6. Audio In 1 / Microphone Connector √ √
7. Kensington
TM
Lock Port √ √
8. Audio Out Connector √ √
9. Audio In 2 Connector √ √
10. VGA Out Connector √ √
11. RS232 Connector √ √
12. RJ-45 Connector √ √
13. Power Socket √ √
14. VGA In 2 Connector √ √
15. S-Video Connector √ √
16. HDBaseT Connector N/A √
Note: “√” means the item is supported, “N/A” means the item is not available.
