13
• UL6200/RL310/LU-X500/SL510/FL-140/FNX1704/UL5230/RL113/LU-X400/SL410/
FL-123/FNX1708/UL5210/RL110/LU-X300/SL310/FL-120/FNX1712
4:3 Signal Input (Normal Mode)
x : Picture size (diag.) (in/cm)
L1: Projection distance from the screen side of the projector to the screen(cm)
L2: Projection distance from the center of the projection window to the screen (cm)
H: Distance from the projector bottom to the bottom of the image (cm)
Picture (Screen) size Projection distance [L]
H
Diag. [x] Width Height L1 L2
125" (318 cm) 254.0 cm 190.5 cm 45.1 cm 76.1 cm 43.2 cm
100" (254 cm) 203.2 cm 152.4 cm 29.1 cm 60.1 cm 36.5 cm
80" (203 cm) 162.6 cm 121.9 cm 16.3 cm 47.3 cm 31.1 cm
65" (165 cm) 132.1 cm 99.1 cm 6.7 cm 37.7 cm 27.0 cm
