Preparation before assemble:
1.Clean the room for work
2.Identify the area for material
3.Prepare the implement, equipment, materials as bellow：
1) working table
2) Screw-driver
3) Knife
4) glove
5) cleaning cloth
6) ESD protection
After unplugging the power cord, the power board still have power energe. Please pay attention when
disassembling/assembling Power BD.
S1
Assemble I/F BD and P/BD
Before Disassembling & Assembling, monitor need to be put on the sponge
and the Insulation glove must be wore during the process.
Assemble the SPK to the SHD, stick the SPK-Wire with tape and stick one tape on the
SHD remarked with red circle and as picture 1.
Insert the FFC to the I/F BD as picture 2.
Insert the P/BD-Wire to the I/F BD and the P/B, place the I/F BD and the Power BD to
main SHD and lock all screws as picture 3.
Put Mylar on the Power BD as picture 4.
PICTURE 1
PICTURE 2 PICTURE 3 PICTURE 4
S2
Assemble the Bezel,
CTRL-BD and Panel
Insert the CTRL BD-FFC to CTRL BD as circle frame, and insert them into the bezel.
Assemble the panel on the bezel.
Stick Mylar on CTRL BD FFC as square frame and Insert the CTRL BD -FFC to the
PCBA as circle frame.
To Next Page
