Acer V223HQ Product Service Manual

- 13 -
AUO M215HW01
Item
Condition
Spec
OK
N.A
Remark
Resolution
Any input resolution modes
which are under 1920x1080
1920x1080

Contrast ratio
600(min),1000(typ.)

Test Condition: Set
Contrast at 50,
Brightness at 100,
Color at User preset.
Brightness
At R/G/B saturated condition
300 cd/m
2
(typ.),240 cd/m
2
(min)

Test Condition: Set
Contrast at 50,
Brightness at 100,
Color at User preset.
Response time
Rising + Falling time
On/off:5 ms (typ.),8ms(max)

Test Equipment:
Westar TRD 100 or
equal level equipment ;
Viewing angle
At Contrast ratio = 10
R/L: 170 degrees (typ.)
150 degrees (min)

At Contrast ratio = 10
U/D:160 degrees (typ.)
140 degrees(min)

CIE coordinate of White
(0.313, 0.329) +/- (0.03, 0.03)

Display colors
16.7 Millions colors

6 bit+Hi-FRC
3.3.2 Brightness Adjustable Range
Item
Condition
Spec
OK
N.A
Remark
Brightness adjustable range
At default contrast level
(saturate point) & Full-white
color pattern
(Max. brightness value –
Min. brightness value)
≧ 100 cd/㎡

3.3.3 Acoustical Noise
Item
Condition
Spec
OK
N.A
Remark
Acoustical Noise
At 30 cm distance
≦ 22 dB/A

Refer to C326
3.3.4 Environment
Item
Condition
Spec
OK
N.A
Remark
Temperature
Operating
0 ~ +40 ℃

Non-operating
-20 ~ +60 ℃

Humidity
Operating
10 ~ 90%

Non-condensing
Non-operating
10 ~ 90%

Non-condensing
Altitude
Operating
0~3048m (10,000ft)

Without packing
Non-operating
0~12,192m (40,000ft)

With packing
3.3.5 Transportation
Item
Condition
Spec
OK
N.A
Remark
(1) Vibration
Package, Non-Operating
Test Specification:
1. Frequency Hertz 5 ~
250 HZ , PSD Level
0.0054 (G2/Hz)
2. Grms = 1.146
3. Sweep Time : 30
minutes per Axis
4. Axes : X,Y,Z


Acer V223HQ Specifications

General

Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display diagonal	21.5 \
Vertical scan range	55 - 75 Hz
Horizontal scan range	30 - 80 kHz
Viewable size, vertical	268 mm
Contrast ratio (typical)	-
Viewable size, horizontal	476.6 mm
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Power management	ENERGY STAR
Display viewable area (HxV)	476.6 x 268 mm
Mean time between failures (MTBF)	50000 h
Certification	TCO03
Product color	Black
Cable lock slot	Yes
Tilt angle range	-5 - 15 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (off)	0.67 W
Power consumption (standby)	0.79 W
Power consumption (typical)	30 W

Weight and Dimensions

Depth (without stand)	195 mm
Width (without stand)	371.52 mm
Height (without stand)	507.84 mm
Weight (without stand)	4500 g
