Acer V223HQ Product Service Manual

- 19 -
3.6.4 Carton
Item
Condition
Spec
OK
N.A
Remark
Color
Kraft

Material
B Flute

Compression strength
200KGF

Burst Strength
16 KGF/cm
2

Stacked quantity
5 Layers Vertical

3.7. Pallet & Shipment
3.7.1 Container Specification
Stowing Type
1.1.1.1.1.1.1 C
ontainer
Quantity of products
(sets)
(Every container)
Quantity of Products
(sets)
(Every Pallet)
Quantity of pallet
(sets)
(Every Container)
With pallet
20'
800
Pallet A: 80
Pallet A: 10
Pallet B: --
Pallet B:
40'
1760
Pallet A: 80
Pallet A: 22
Pallet B: --
Pallet B:
Without pallet
20'
X
X
X
X
X
X
40'
X
X
X
X
X
X
3.7.2 Carton Specification
3.7.2.1 Product:
Net Weight (Kg)
Gross Weight (Kg)
Dimension w/o Base
W*H*D (mm)
Dimension w/ Base
W*H*D (mm)
4.115 Kg
5.755 Kg
507.84x371.52x195
3.7.2.2 Package:
Carton Interior Dimension (mm)
L*W*H
Carton External Dimension (mm)
L*W*H
548 x 412 x 120
556x418x128 mm
3.8. Certification
Item
Condition
Spec
OK
N.A
Remark
Environment
Green design
API Doc. 715-C49

ISO14000
Requirement
Blue Angel
German Standard

E-2000
Switzerland

EPA
USA Standard

TCO’99

TCO’03

MPR2

Green Mark

PC-Monitor
Microsoft Windows
PC98/99


Acer V223HQ Specifications

General

Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display diagonal	21.5 \
Vertical scan range	55 - 75 Hz
Horizontal scan range	30 - 80 kHz
Viewable size, vertical	268 mm
Contrast ratio (typical)	-
Viewable size, horizontal	476.6 mm
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Power management	ENERGY STAR
Display viewable area (HxV)	476.6 x 268 mm
Mean time between failures (MTBF)	50000 h
Certification	TCO03
Product color	Black
Cable lock slot	Yes
Tilt angle range	-5 - 15 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (off)	0.67 W
Power consumption (standby)	0.79 W
Power consumption (typical)	30 W

Weight and Dimensions

Depth (without stand)	195 mm
Width (without stand)	371.52 mm
Height (without stand)	507.84 mm
Weight (without stand)	4500 g
