Acer V223HQ Product Service Manual

- 16 -
Display mode
Normally White

Support color
16.7Millions colors

6 bit + HiFRC
AUO M215HW01
Item
Condition
Spec
OK
N.
A
Remark
LCD Panel Supplier
AUO

Panel type of Supplier
AUO M215HW01

Screen Diagonal
546.86mm(21.5.”)

Display area
Unit=mm
476.64(H) x 268.11(V)

Physical Size
Unit=mm
495.6(H) x 292.2(V) x 16.35(D)

Weight
Unit=gram
2188 (typ.)

Technology
TN type

Pixel pitch
Unit=um
248.25(H) x248.25 (W)

Per one triad
Pixel arrangement
R/G/B vertical stripe

Display mode
Normally White

Support color
16.7Millions colors

6 bit + HiFRC
3.4.2-1 Optical characteristics of LCD panel
LGD LM215WF1 TLA1
Item
Unit
Conditions
Min.
Typ.
Max.
Remark
Viewing Angle
[degree]
[degree]
Horizontal (Right)
CR = 10 (Left)
140
170
-
-
[degree]
[degree]
Vertical
(Up)
CR = 10 (Down)
130
160
-
-
Contrast ratio
Normal Direction
700
1000
Response Time
[msec]
Rising Time
-
1.3
2.6
[msec]
Falling Time
-
3.7
7.4
[msec]
Rising + Falling
-
5
10
Color / Chromaticity
Coordinates (CIE)
Red x
0.646
Red y
0.334
Green x
0.303
Green y
0.616
Blue x
0.147
Blue y
0.067
Color Coordinates (CIE) White
White x
0.313
White y
0.329
Luminance Uniformity
[%]
9 points measurement
75
White Luminance @ CCFL
7.0mA (center)
[cd/m
2
]
250
300
-
Crosstalk (in 75Hz)
[%]
1.5
* The test methods for the above items’ definition, please refer to the relative panel specification.
AUO M215HW01
Item
Unit
Conditions
Min.
Typ.
Max.
Remark
Viewing Angle
[degree]
[degree]
Horizontal (Right)
CR = 10 (Left)
150
170
-
-
[degree]
[degree]
Vertical
(Up)
CR = 10 (Down)
140
160
-
-

Acer V223HQ Specifications

General

Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display diagonal	21.5 \
Vertical scan range	55 - 75 Hz
Horizontal scan range	30 - 80 kHz
Viewable size, vertical	268 mm
Contrast ratio (typical)	-
Viewable size, horizontal	476.6 mm
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Power management	ENERGY STAR
Display viewable area (HxV)	476.6 x 268 mm
Mean time between failures (MTBF)	50000 h
Certification	TCO03
Product color	Black
Cable lock slot	Yes
Tilt angle range	-5 - 15 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (off)	0.67 W
Power consumption (standby)	0.79 W
Power consumption (typical)	30 W

Weight and Dimensions

Depth (without stand)	195 mm
Width (without stand)	371.52 mm
Height (without stand)	507.84 mm
Weight (without stand)	4500 g
