ACMER P2 - Installation Steps; Preparation and Components; Installing the Base Unit

Front Component x 1
Left Component x 1
6.1 You will need to prepare the following sections.
6.1.1 Install the box in the direction shown and place it on a horizontal table.
6.Installation Steps
Right component x 1
M3*6 Screw x 12
Rear Component x 1
