ACORN 80 Installation Manual
APPENDIX 10
Rationalisation Procedures
7 Remove Seat swivel pin from the base of the seat by unscrewing the grub screw.
REMOVE SWIVEL PIN
FROM EITHER SIDE OF
THE SEAT BASE
8 Reconnect the Seat interlock harness onto the board as shown and secure the harness in place with
4 x Tie wraps.
RECONNECT HARNESS
TO MAIN PCB
SECURE WITH 4x
TIE WRAPS
