ACORN 80 Installation Manual
APPENDIX 10
Rationalisation Procedures
5 Feed Arm/Switch Harness (1021541) through the rear and centre
of the mainframe as shown, and connect to the PCB as shown.
HARNESS FED
THROUGH THE REAR
OF THE MAINFRAME
CASTING
CONNECT ARM
HARNESS
TO THE PCB
FEED HARNESS
THROUGH THE CENTRE
OF THE MAINFRAME
