Signal Acquisition Modes and Real-Time Processing

Acqiris SA240P User's Manual 17

Chapter 2

SignalAcquisitionModesandReal-Time

Processing

Thanks to the powerful Xilinx Kintex Ultrascale FPGA, the SA240P enables real-time signal pre-

processing on the sampled data e.g. data compression or noise reduction. This allows to save

analysis time and make the user application running faster. Acqiris proposes various firmware and

real-time processing features in the FPGA, so on-board processing can be optimized for each

application and eventually for each of your system.

This section details the acquisition modes.

2.1 Digitizer acquisition mode 18

2.2 Real-time averaging mode (AVG option) 22

The modes available with your product depends on the firmware options ordered with your

products. To check which options and mode are present on your ADC card you can use the MD3

Software Front Panel from the: Windows Start Menu > Acqiris > MD3 > Acqiris MD3 SFP.

Then use the menu Help > About. The field System Options gives the option list.

Easy mode switch

A simple change of acquisition mode allows to automatically switch, for instance, from the digitizer

to the average mode. The corresponding firmware switches automatically.
