6.4 Initial configuration
Acqiris SA240P User's Manual 67
6.4 Initial configuration
At initialization, the driver uses the pre-defined defaults values. The following table details the initial
configuration of the ADC card.
Property Default value Comment
Channeli (with i = 1, 2)
Enable
Input filter Bypass = false By default, the bandwidth limiter is disable
Vertical range 1 (Volts)
Vertical offset 0 (Volts)
Vertical coupling DC
Trigger source Internal1
Trigger delay 0 (ns)
Trigger type Edge
Trigger coupling DC
Trigger level 0 (Volts)
Trigger slope Positive
Interleave Disable
Mode Normal (DGT)
Sampling rate 4 GS/s
Sample clock Internal
Reference oscillator Internal
Reference oscillator frequency 10 MHz Fixed
Record size 1024
Number of records to acquire 1
Number of averages 1 for AVG mode only
