acrison 105-BB - OUTLINE SCHEMATICS Basic Feeder Outline- Figure 1

FIGURE 1
%$6,&)(('(5287/,1(
1.
Motor
2.
Gear-reducer
3.
Gearbox
4.
Feeder Mounting Base
5.
Seal Housing Assembly
6.
Conditioning Chamber
12.
Discharge Cylinder
13.
Supply Hopper
NOTE:
The Numerical Component
designations indicated in this
Illustration are for reference
purposes only for use within
this Instruction Manual.
24
