AR-B1579 User's Guide
2-5
Name Description
IOCHRDY
[Input, Open collector]
This signal lengthens the I/O, or memory read/write
cycle, and should be held low with a valid address
IRQ 3-7, 9-12, 14, 15
[Input]
The Interrupt Request signal indicates I/O service
request attention. They are prioritized in the following
sequence : (Highest) IRQ 9, 10, 11, 12, 13, 15, 3, 4, 5,
6, 7 (Lowest)
-IOR
[Input/Output]
The I/O Read signal is an active low signal which
instructs the I/O device to drive its data onto the data
bus
-IOW [Input/Output]
The I/O write signal is an active low signal which
instructs the I/O device to read data from the data bus
-MRD16 [Output]
The System Memory Read is low while any of the low 1
mega bytes of memory are being used
-MEMR
[Input/Output]
The Memory Read signal is low while any memory
location is being read
-MWR16 [Output]
The System Memory Write is low while any of the low 1
mega bytes of memory is being written
-MEMW
[Input/Output]
The Memory Write signal is low while any memory
location is being written
DRQ 0-3, 5-7 [Input]
DMA Request channels 0 to 3 are for 8-bit data
transfers. DMA Request channels 5 to 7 are for 16-bit
data transfers. DMA request should be held high until
the corresponding DMA has been completed. DMA
request priority is in the following sequence:(Highest)
DRQ 0, 1, 2, 3, 5, 6, 7 (Lowest)
-DACK 0-3, 5-7
[Output]
The DMA Acknowledges 0 to 3, 5 to 7 are the
corresponding acknowledge signals for DRQ 0 to 3 and
5 to 7
AEN [output]
The DMA Address Enable is high when the DMA
controller is driving the address bus. It is low when the
CPU is driving the address bus
-REFRESH
[Input/Output]
This signal is used to indicate a memory refresh cycle
and can be driven by the microprocessor on the I/O
channel
TC [Output]
Terminal Count provides a pulse when the terminal
count for any DMA channel is reached
SBHE [Input/Output]
The System Bus High Enable indicates the high byte
SD8 - SD15 on the data bus
-MASTER [Input]
The MASTER is the signal from the I/O processor which
gains control as the master and should be held low for a
maximum of 15 microseconds or system memory may
be lost due to the lack of refresh
-MEMCS16
[Input, Open collector]
The Memory Chip Select 16 indicates that the present
data transfer is a 1-wait state, 16-bit data memory
operation
-IOCS16
[Input, Open collector]
The I/O Chip Select 16 indicates that the present data
transfer is a 1-wait state, 16-bit data I/O operation
OSC [Output]
The Oscillator is a 14.31818 MHz signal
ZWS
[Input, Open collector]
The Zero Wait State indicates to the microprocessor
that the present bus cycle can be completed without
inserting additional wait cycle
Table 2-5 I/O Channel Signal Description
