3.2.3 Hard Disk (IDE) Connector
40-Pin Hard Disk (IDE) Connector (CN1)
A 40-pin header type connector (CN1) is provided to interface with up to two embedded hard disk drives (IDE AT
bus). This interface, through a 40-pin cable, allows the user to connect up to two drives in a “daisy chain” fashion.
To enable or disable the hard disk controller, please use the BIOS Setup program. The following table illustrates
the pin assignments of the hard disk drive’s 40-pin connector.
1
240
39
Figure 3-4 CN1: Hard Disk (IDE) Connector
Pin Signal Pin Signal
1 -RESET 2 GROUND
3 DATA 7 4 DATA 8
5 DATA 6 6 DATA 9
7 DATA 5 8 DATA 10
9 DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GROUND 20 NOT USED
21 IDEDRQA 22 GROUND
23 -IOW A 24 GROUND
25 -IOR A 26 GROUND
27 -CHRDY A 28 GROUND
29 DACKA 30 GROUND
31 -IRQ 14 32 NOT USED
33 SA 1 34 NOT USED
35 SA 0 36 SA 2
37 CS 0 38 CS 1
39 HD LED A 40 NOT USED
Table 3-1 CN1: Hard Disk (IDE) Connector
