Ultrasonic flaw detector А1212 MASTER
Operation Manual
35
ACOUSTIC
CONTROL
SYSTEMS
2
Figure 30
Figure 31
Table 15
Discreteness of the
readings
0.1 / 1 Selects the displayed discreteness of the results
Cursor On/Off
Controls the display of the measuring cursor (vertical line pointing at the place
of measurement of the signal parameters) on the screen (
key).
Cut-off, %
Off / from 1 to 100
with step 1
Level of the cut-off when the signal is displayed on the screen. Cut-off removes
the noise signals from the screen. Amplitude of these noise signals is below
the selected threshold value
Parameter name Value Description
▼
