ASCON Service Guide Book
47
Wall Mounted F Series Heat Pump Model
Model Board Handset
WM 10/15/20/25FR, 301R U1.5 G8
LED Indicator Light Display
LED Light Diagnosis Table
Operation / Faulty Indication
Cooling mode
Dry mode
Fan mode
Heating mode
Auto mode in heating operation
Auto mode in cooling operation
Defrost mode
Compressor overload
protection
Indoor coil sensor contact
loose / short
Outdoor coil sensor contact
loose / short
Room air sensor contact loose
/ short
Gas leak
COOL
(Green)
HEAT / FAN
(Red / Green)
DRY
(Orange)
SLEEP
(Red)
To Next Page
